The INVIZ SNK tank inspection camera / vessel inspection camera accessory

The tank inspection camera / vessel inspection camera INVIZ SNK provides you a wide range of videoscope accessories for Remote Visual Inspection (RVI). Benefit from optional accessories like the optional LED front ring for the tank inspection camera, the vessel camera trolly and other useful accessories for your Remote Visual Inspections with the INVIZ SNK tank and vessel inspection camera.





工业内窥镜,水下电视,紫外uv视频内窥镜

工业内窥镜,水下电视,紫外uv视频内窥镜

可选配镜头专用存储箱

Dimensions in mm / inch: (W) 415 / 16.34” x (H) 465 / 18.31” x (D) 190 / 7.48”

Weight: 3,25 kg / 7.16 lbs, transport case for inspection cameras INVIZ SNK / INVIZ Revolver 80.




工业内窥镜,水下电视,紫外uv视频内窥镜

可选配线缆存储软布包

Accessory soft pack including standard main cable soft bag (up to 50 meter / 164 ft.)




工业内窥镜,水下电视,紫外uv视频内窥镜

可选配专用线缆转轴

Allows to wind and unwind cable during operation up to 200 m (640 ft.) cable.




工业内窥镜,水下电视,紫外uv视频内窥镜

可选配镜头可升降装置

Allows camera tranport into vessels from the bottom. Max. height: 5 m (16.4 ft.).




工业内窥镜,水下电视,紫外uv视频内窥镜

可选配镜头推送装置

Pushing trolly as guidance in tubes for long distances (longer than 3 m / 9.84 ft.)




工业内窥镜,水下电视,紫外uv视频内窥镜

可选配人孔支撑装置

Supporting the inspection of vessels / cavities with precisely guidance of the INVIZ SNK, mounted to the push poles.




工业内窥镜,水下电视,紫外uv视频内窥镜

可选配快速组装推送器

For mounting and guiding of the camera head in the application. Push poles available in 1 m / 3.28 ft. and 2 m / 6.56 ft. length. The Soft bag allows easy transportation of over 10 push poles.




工业内窥镜,水下电视,紫外uv视频内窥镜

可选配镜头安装适配器

Connecting the push poles with the INVIZ SNK camera head. Stainless steel.




工业内窥镜,水下电视,紫外uv视频内窥镜

可选配镜头安装适配器 L型

Extends the inspection capabilities in complex geometry by positioning the camera head 90° horizontal.




工业内窥镜,水下电视,紫外uv视频内窥镜

可选配压力供应套装

Incl. CO2 one-way cartridges. Check camera before inspection to be waterproof. Increase your water depth inspection range by pre pressurisation.







Remote Visual Inspection in

  • Remote Visual Inspection in refineries
  • Remote Visual Inspection in tanks / vessels
  • Remote Visual Inspection in nuclear industry
  • Remote Visual Inspection in power generation
